GitHub Actions Deploy to VPS: Complete CI/CD Guide

Set up automated deployments from GitHub to your VPS. Push to main, and your changes go live automatically.

Overview

This guide covers three deployment strategies:

SSH and pull - Simple, good for small projects
Docker image via registry - Better for production
Zero-downtime with health checks - Best for critical apps

Pick the one that matches your needs.

Prerequisites on your VPS

Ensure Docker is installed:

curl -fsSL https://get.docker.com | sh
sudo usermod -aG docker $USER

Create a deploy user (recommended over using root):

sudo adduser deploy
sudo usermod -aG docker deploy
sudo usermod -aG sudo deploy

Step 1: Set up SSH key authentication

On your local machine, generate a deployment key:

ssh-keygen -t ed25519 -C "github-actions-deploy" -f ~/.ssh/deploy_key -N ""

Copy the public key to your VPS:

ssh-copy-id -i ~/.ssh/deploy_key.pub deploy@YOUR_VPS_IP

Test the connection:

ssh -i ~/.ssh/deploy_key deploy@YOUR_VPS_IP "echo 'Connection successful'"

Step 2: Add secrets to GitHub

Go to your repository on GitHub:

Settings > Secrets and variables > Actions
Add these repository secrets:

Secret Name	Value
`VPS_HOST`	Your VPS IP address
`VPS_USER`	`deploy` (or your deploy user)
`VPS_SSH_KEY`	Contents of `~/.ssh/deploy_key` (private key)
`VPS_PORT`	`22` (or your SSH port)

To copy the private key:

cat ~/.ssh/deploy_key

Copy everything including the -----BEGIN and -----END lines.

Strategy 1: SSH and pull (simplest)

This strategy SSHes into your VPS, pulls the latest code, and rebuilds.

Create .github/workflows/deploy.yml:

name: Deploy to VPS

on:
  push:
    branches:
      - main

jobs:
  deploy:
    runs-on: ubuntu-latest
    steps:
      - name: Deploy via SSH
        uses: appleboy/[email protected]
        with:
          host: ${{ secrets.VPS_HOST }}
          username: ${{ secrets.VPS_USER }}
          key: ${{ secrets.VPS_SSH_KEY }}
          port: ${{ secrets.VPS_PORT }}
          script: |
            cd ~/apps/your-app
            git pull origin main
            docker compose down
            docker compose up -d --build
            docker image prune -f

Pros:

Simple setup
No registry needed
Good for small projects

Cons:

Build happens on VPS (uses VPS resources)
Downtime during rebuild
Slower for large builds

Strategy 2: Docker image via registry (recommended)

Build on GitHub, push to a registry, pull on VPS.

Set up GitHub Container Registry

Add another secret to your repository:

Secret Name	Value
`GHCR_TOKEN`	Your GitHub Personal Access Token with `write:packages` scope

Or use the automatic GITHUB_TOKEN (simpler).

Create the workflow

Create .github/workflows/deploy.yml:

name: Build and Deploy

on:
  push:
    branches:
      - main

env:
  REGISTRY: ghcr.io
  IMAGE_NAME: ${{ github.repository }}

jobs:
  build:
    runs-on: ubuntu-latest
    permissions:
      contents: read
      packages: write

    outputs:
      image_tag: ${{ steps.meta.outputs.tags }}

    steps:
      - name: Checkout repository
        uses: actions/checkout@v4

      - name: Set up Docker Buildx
        uses: docker/setup-buildx-action@v3

      - name: Log in to Container Registry
        uses: docker/login-action@v3
        with:
          registry: ${{ env.REGISTRY }}
          username: ${{ github.actor }}
          password: ${{ secrets.GITHUB_TOKEN }}

      - name: Extract metadata
        id: meta
        uses: docker/metadata-action@v5
        with:
          images: ${{ env.REGISTRY }}/${{ env.IMAGE_NAME }}
          tags: |
            type=sha,prefix=
            type=raw,value=latest

      - name: Build and push
        uses: docker/build-push-action@v5
        with:
          context: .
          push: true
          tags: ${{ steps.meta.outputs.tags }}
          cache-from: type=gha
          cache-to: type=gha,mode=max

  deploy:
    needs: build
    runs-on: ubuntu-latest

    steps:
      - name: Deploy to VPS
        uses: appleboy/[email protected]
        with:
          host: ${{ secrets.VPS_HOST }}
          username: ${{ secrets.VPS_USER }}
          key: ${{ secrets.VPS_SSH_KEY }}
          port: ${{ secrets.VPS_PORT }}
          script: |
            cd ~/apps/your-app

            # Pull the latest image
            docker pull ghcr.io/${{ github.repository }}:latest

            # Update the running container
            docker compose down
            docker compose up -d

            # Clean up old images
            docker image prune -f

Update your docker-compose.yml on the VPS to use the registry image:

services:
  app:
    image: ghcr.io/yourusername/your-repo:latest
    restart: unless-stopped
    # ... rest of your config

echo $GITHUB_TOKEN | docker login ghcr.io -u yourusername --password-stdin

Pros:

Build happens on GitHub runners (free)
Faster deploys (just pull, no build)
Versioned images for rollbacks

Cons:

More setup
Requires registry access on VPS

Strategy 3: Zero-downtime deployment

Use Docker Compose with health checks and rolling updates.

Update docker-compose.yml

services:
  app:
    image: ghcr.io/yourusername/your-repo:latest
    restart: unless-stopped
    deploy:
      replicas: 2
      update_config:
        parallelism: 1
        delay: 10s
        failure_action: rollback
      rollback_config:
        parallelism: 1
        delay: 10s
    healthcheck:
      test: ["CMD", "curl", "-f", "http://localhost:3000/health"]
      interval: 10s
      timeout: 5s
      retries: 3
      start_period: 40s
    labels:
      - traefik.enable=true
      - traefik.http.routers.app.rule=Host(`yourdomain.com`)
      - traefik.http.routers.app.tls=true
      - traefik.http.routers.app.tls.certresolver=letsencrypt
      - traefik.http.services.app.loadbalancer.server.port=3000

Add a health endpoint to your app:

// Express example
app.get('/health', (req, res) => {
  res.status(200).json({ status: 'ok' });
});

Update the workflow

name: Zero-Downtime Deploy

on:
  push:
    branches:
      - main

env:
  REGISTRY: ghcr.io
  IMAGE_NAME: ${{ github.repository }}

jobs:
  build:
    runs-on: ubuntu-latest
    permissions:
      contents: read
      packages: write

    steps:
      - uses: actions/checkout@v4

      - uses: docker/setup-buildx-action@v3

      - uses: docker/login-action@v3
        with:
          registry: ${{ env.REGISTRY }}
          username: ${{ github.actor }}
          password: ${{ secrets.GITHUB_TOKEN }}

      - name: Build and push
        uses: docker/build-push-action@v5
        with:
          context: .
          push: true
          tags: |
            ${{ env.REGISTRY }}/${{ env.IMAGE_NAME }}:${{ github.sha }}
            ${{ env.REGISTRY }}/${{ env.IMAGE_NAME }}:latest
          cache-from: type=gha
          cache-to: type=gha,mode=max

  deploy:
    needs: build
    runs-on: ubuntu-latest

    steps:
      - name: Zero-downtime deploy
        uses: appleboy/[email protected]
        with:
          host: ${{ secrets.VPS_HOST }}
          username: ${{ secrets.VPS_USER }}
          key: ${{ secrets.VPS_SSH_KEY }}
          port: ${{ secrets.VPS_PORT }}
          script: |
            cd ~/apps/your-app

            # Pull new image
            docker pull ghcr.io/${{ github.repository }}:${{ github.sha }}

            # Tag as latest
            docker tag ghcr.io/${{ github.repository }}:${{ github.sha }} \
                       ghcr.io/${{ github.repository }}:latest

            # Rolling update
            docker compose up -d --no-deps --scale app=2 app

            # Wait for health checks
            sleep 30

            # Remove old containers
            docker compose up -d --no-deps --scale app=1 app

            # Cleanup
            docker image prune -f

      - name: Verify deployment
        uses: appleboy/[email protected]
        with:
          host: ${{ secrets.VPS_HOST }}
          username: ${{ secrets.VPS_USER }}
          key: ${{ secrets.VPS_SSH_KEY }}
          port: ${{ secrets.VPS_PORT }}
          script: |
            curl -f https://yourdomain.com/health || exit 1

Running tests before deploy

Add a test job:

jobs:
  test:
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v4

      - uses: actions/setup-node@v4
        with:
          node-version: '20'
          cache: 'npm'

      - run: npm ci
      - run: npm test
      - run: npm run lint

  build:
    needs: test
    # ... rest of build job

Environment-specific deploys

Deploy to staging on PR, production on main:

name: Deploy

on:
  push:
    branches:
      - main
  pull_request:
    branches:
      - main

jobs:
  deploy-staging:
    if: github.event_name == 'pull_request'
    runs-on: ubuntu-latest
    environment: staging
    steps:
      - name: Deploy to staging
        uses: appleboy/[email protected]
        with:
          host: ${{ secrets.STAGING_HOST }}
          username: ${{ secrets.VPS_USER }}
          key: ${{ secrets.VPS_SSH_KEY }}
          script: |
            cd ~/apps/your-app-staging
            docker compose pull
            docker compose up -d

  deploy-production:
    if: github.event_name == 'push' && github.ref == 'refs/heads/main'
    runs-on: ubuntu-latest
    environment: production
    steps:
      - name: Deploy to production
        uses: appleboy/[email protected]
        with:
          host: ${{ secrets.VPS_HOST }}
          username: ${{ secrets.VPS_USER }}
          key: ${{ secrets.VPS_SSH_KEY }}
          script: |
            cd ~/apps/your-app
            docker compose pull
            docker compose up -d

Deployment notifications

Add Slack or Discord notifications:

  notify:
    needs: deploy
    runs-on: ubuntu-latest
    if: always()
    steps:
      - name: Notify on success
        if: needs.deploy.result == 'success'
        uses: slackapi/[email protected]
        with:
          payload: |
            {
              "text": "Deployed ${{ github.repository }} to production",
              "blocks": [
                {
                  "type": "section",
                  "text": {
                    "type": "mrkdwn",
                    "text": "*Deployed to production*\nRepo: ${{ github.repository }}\nCommit: ${{ github.sha }}"
                  }
                }
              ]
            }
        env:
          SLACK_WEBHOOK_URL: ${{ secrets.SLACK_WEBHOOK }}

      - name: Notify on failure
        if: needs.deploy.result == 'failure'
        uses: slackapi/[email protected]
        with:
          payload: |
            {
              "text": "Deployment failed for ${{ github.repository }}",
              "blocks": [
                {
                  "type": "section",
                  "text": {
                    "type": "mrkdwn",
                    "text": "*Deployment failed*\nRepo: ${{ github.repository }}\nCheck: ${{ github.server_url }}/${{ github.repository }}/actions/runs/${{ github.run_id }}"
                  }
                }
              ]
            }
        env:
          SLACK_WEBHOOK_URL: ${{ secrets.SLACK_WEBHOOK }}

Rollback strategy

Keep the previous image for quick rollbacks:

# On VPS, before deploying
docker tag ghcr.io/you/app:latest ghcr.io/you/app:previous

# To rollback
docker tag ghcr.io/you/app:previous ghcr.io/you/app:latest
docker compose up -d

Or use specific commit SHA tags:

# Rollback to specific version
docker pull ghcr.io/you/app:abc1234
docker tag ghcr.io/you/app:abc1234 ghcr.io/you/app:latest
docker compose up -d

Troubleshooting

SSH connection refused

Verify the IP address is correct
Check SSH is running: sudo systemctl status ssh
Check firewall: sudo ufw status
Verify the key was added to authorized_keys

Permission denied (publickey)

Ensure the private key in GitHub Secrets includes all lines
Check key permissions on VPS: chmod 600 ~/.ssh/authorized_keys
Verify the username matches

Docker pull fails on VPS

echo $GITHUB_TOKEN | docker login ghcr.io -u yourusername --password-stdin

Check the image visibility (must be public or you need auth).

Workflow never triggers

Check the branch name matches exactly
Verify the workflow file is in .github/workflows/
Check the YAML syntax is valid

Build succeeds but deploy fails

Check the SSH script output in GitHub Actions logs. Common issues:

Wrong directory path
Missing environment variables
Docker Compose syntax errors
